JH430X XPON+4GE+USB2.0+1POTS+WiFi AC1200 PON network router

  • XPON Dual Mode
  • SN and LOID+Password multiple registration methods
  • Support VLAN transparent/ tag/ translate/ trunk
  • Support Layer 2 802.1Q VLAN, 802.1P QoS, ACL etc
  • IPv4, IPv6 and IPv4/IPv6 dual stack
  • Support bridge, router & bridge/router mixed mode
  • DHCP v4/v6 Client/Server, PPPoE & Static
  • Support Static Routing
  • Support hardware NAT
  • Support IGMP V2 and MLD proxy/ snooping
  • Support MultiCast VLAN & MultiCast Maximum Address
  • DDoS, Filtering Based on ACL/MAC/URL
  • Support DDNS, ALG, UPnP, Port forwarding, DMZ
  • HTTP/SSH/Telnet Service Access Control
  • Support Parent control
  • Support PPTP , L2TP, Pass-through service
  • Support 4 queues
  • Support SP, WRR, 802.1P and DSCP
  • SIP and IMS SIP
  • G.711a/G.711u/G.722/G.729/G.723/G.726 Codec
  • Echo cancellation, VAD/CNG, DTMF Relay
  • T.30/T.38 FAX
  • Caller Identification/Call Waiting/Call Forwarding/Call Transfer/Call Hold/3-way Meeting conference
  • Line testing according to GR-909
  • Support high-quality broadband voice
  • Integrated 802.11b/g/n/ac
  • Authentication:WEP/WAP-PSK(TKIP)/WAP2-PSK(AES)
  • Modulation type:DSSS,CCK and OFDM
  • Easymesh
  • Support Telnet, CLI, OMCI/OAM ,TR069 and Web management
  • Wi-Fi6:802.11a/n/ac/ax 5GHz & 802.11g/b/n/ax 2.4GHz
  • WiFi Encryption:WEP-64/WEP-128/ WPAWPA2/PA3
  • Support WiFi Easy-mesh function

分类：

    JH430X is 4GE+POTS+AX3000 with USB optional XPON(GPON and GEPON dual mode) HGU ONU.The device isfuly comply with ITU-T G.984/G988 and lEEE802.3ah. The equipment integrates the reliability, maintainability andsecurity design of carrier-grade level, and provides customers with the last kilometer of broadband access toresidential and corporate customers. lt can also be applied to a strictly temperature environment, and can workstable for longtime without service interruption.



JH430X is interoperable with all brands of OLT and is Easy to install, provisioning and maintenance. The device canidentify the working mode of the OLT to automatically complete the switch between GPON and EPON, The devicecan be freely switched between bridge and routing modes, and supports PPPoE dial-up and IPv6 functions in routingmode to meet the needs of different scenarios.
